SNADI's three-phase hybrid inverter is a top-quality and dependable option for commercial solar energy systems. Our hybrid inverter offers advanced MPPT technology and designed with robust materials and an easy-to-use interface, making it an excellent choice for any large-scale solar energy project.
●Pure sine wave 220VAC/380VAC
●Built-in MPPT 100A
●Gel battery activation function Utility
●Compatible work with gel battery
●Pure Sine Wave-Power factor 1.0
●LCD real-time display of the device parameters, running state at a glance
●Detachable dust cover for harsh environment
●Low frequency(Built in Square transformer)
●Support multiple output priority: SBU,SUB
●Communication interface:RS232/RS485/Dry contact
●EQ function to optimize battery performance and extend lifecycle
●Pure sine wave 220VAC/380VAC
●Built-in MPPT 100A
●Gel battery activation function Utility
●Compatible work with gel battery
●Pure Sine Wave-Power factor 1.0
●LCD real-time display of the device parameters, running state at a glance
●Detachable dust cover for harsh environment
●Low frequency(Built in Square transformer)
●Support multiple output priority: SBU,SUB
●Communication interface:RS232/RS485/Dry contact
●EQ function to optimize battery performance and extend lifecycle
Customized production that meets your needs
Model：10KW、15KW、20KW、30KW
Model：10KW、15KW、20KW、30KW
-
NKG-40KW
-
SNADI
Power
40KW
Battery Type
Lead Acid
Output wave
Pure Sine Wane
Input frequency
45-65Hz
Efficiency
>95%
Size
635*566*1295MM
Packge size
760*690*1540MM
| Model | NKG-10K | NKG-15K | NKG-20K | NKG-30K | |
| Rated Power | 10000W | 15000W | 20000W | 30000W | |
| Battery | Battery Voltage | 192/220/240VDC | |||
| Voltage of Over Discharge Protection | 168/189/210VDC | ||||
| Restart Voltage After Low Battery | 216/243/270VDC | ||||
| MPPT Controller | Controller Types | With maximum power point tracking(MPPT) function controller | |||
| Rated Current | Solar1:50A Solar2:50A | ||||
| Current Limiting Protection | Solar1:52A Solar2:52A | ||||
| Rate Voltage | 192/220/240VDC | ||||
| Operating Voltage Range | 260~420VDC | ||||
| Charge Mode | Three stages:constant current(quick charge), constant pressure, floating charge | ||||
| Battery Type | Sealed lead-acid battery, colloidal lead-acid battery, open lead-acid battery (you can customize parameters to charge other types of batteries) | ||||
| PV Module Input Power | 192VDC:Solar 1,10KW/Solar 2,10KW / 220VDC:Solar 1,11.5KW/Solar 2,11.5KW / 240VDC:Solar 1,12.5KW;Solar 2,12.5KW | ||||
| Vmax-pv | <420VDC | ||||
| Vlow-pv | 240/250/270VDC | ||||
| Vstar-pv | 260/270/290VDC | ||||
| Vovet-pv | 425VDC | ||||
| Floating Charge Voltage (Lead Acid Battery) | 220.8/248.4/275VDC(Can be customized) | ||||
| Average Charging Voltage (Lead Acid Battery) | 232/261/290VDC(Can be customized) | ||||
| PV Module Utilization | ≤99.97% | ||||
| Machine Efficiency | ≥96.5% | ||||
| Output Regulation Accuracy | ≤41.5% | ||||
| Temperature Coefficient | ±0.02%/°C | ||||
| Protective Function | Input and output over-voltage protection,anti-reverse protection,short circuit protection,etc. | ||||
| Inverter | Input Voltage | 380VAC±15% | |||
| Input Frequency | 50/60Hz±5% | ||||
| Output Voltage | 220/380VAC±2% | ||||
| Output Frequency | 50/60Hz±1% | ||||
| Output Wave | Pure Sine Wave THD<4%(full load) | ||||
| Conversion Time | 1~3s | ||||
| Overload | 120%/20s>150%/100ms | ||||
| Efficiency | ≥90%(100% resistive load) | ||||
| Dynamic Load Voltage Transient | <±5%(0~100%) | ||||
| Defensive Function | Output short circuit,overvoltage,low voltage,low battery power protection | ||||
| Other | Operating Ambient Temperature | -10~40°C | |||
| Environment Relative Humidity | 20~90%(No Condensation) | ||||
| Product Size: LWH(mm) | 536*560*1015 | 635*586*1295 | |||
| Weight(KG) | 148 | 165 | 182 | 252 | |
FAQ:
Q1: What is your minimum quanlity order?
A: One set.
Q2: Are you trading company or manufacturer ?
A:We are a manufacturer in China. We have own factory in Foshan.
Q3: What is your term of payment?
A: 30% TT for deposit, balance before the shipping.
Q4:Can you supply the sample?
A: Yes. we can supply the sample order for testing .
Q5: When you can delivery the goods?
A: Sample order 3-5 days ,mass order usually 15-25 days according to the quantity.
Q6: Is this instalation easy?
A: Yes , We will provide install drawing and user manual ,and you can make a video call to get technical support.
Q7: Can you customized it for us?
A: Yes ,we can customize the logo ,color ,size ...
How Can We Help You?
If you have any questions or requirements, please feel free to contact our customer service team. Our professional team will provide you with detailed product information, answer your questions, and tailor the best solution to meet your needs.
Related Products
Experience the future of energy independence with the AS Series Hybrid Solar Inverter. Engineered for both residential and commercial applications, this high-performance On/Off Grid Inverter combines advanced MPPT technology with unparalleled flexibility, supporting battery-less operation and scalable power through seamless parallel connection.
View More Dual Mode Flexibility (On/Off-Grid): Seamlessly switches between grid-tied efficiency and off-grid independence. The AS series is designed to optimize self-consumption while providing reliable backup power.
Battery-Free Operation: A cutting-edge feature that allows the system to power loads directly from solar panels during the day, even without a connected battery bank, significantly reducing initial investment costs.
Scalable Power Architecture: Need more power? Easily expand your system by paralleling up to 6 units, making it ideal for growing energy demands in modern homes or small businesses.
Built-in Dual MPPT Controller: Features high-efficiency MPPT (Maximum Power Point Tracking) to harvest maximum energy from your PV array, even in challenging weather conditions.
Battery-Free Operation: A cutting-edge feature that allows the system to power loads directly from solar panels during the day, even without a connected battery bank, significantly reducing initial investment costs.
Scalable Power Architecture: Need more power? Easily expand your system by paralleling up to 6 units, making it ideal for growing energy demands in modern homes or small businesses.
Built-in Dual MPPT Controller: Features high-efficiency MPPT (Maximum Power Point Tracking) to harvest maximum energy from your PV array, even in challenging weather conditions.
Empower your home with the HDB Series Stacked Solar Energy Storage System. Combining a high-efficiency hybrid inverter with advanced LiFePO4 battery technology, this modular system offers a seamless transition to energy independence. With its flexible stackable design, you can easily scale from 5KWH to 30KWH to meet your evolving power needs.
View More Modular Stackable Efficiency: The HDB series features a plug-and-play stacked architecture, allowing for quick installation and easy capacity expansion without messy wiring.
Premium LiFePO4 Safety: Equipped with high-safety Lithium Iron Phosphate (LiFePO4) batteries, ensuring a reliable 10-year service life and stable energy discharge.
Advanced MPPT Technology: Built-in dual MPPT controllers maximize solar harvesting from your PV panels, ensuring high conversion efficiency even in low-light conditions.
Pure Sine Wave Performance: Delivers clean, stable pure sine wave output, protecting your sensitive electronics and home appliances from power surges.
Smart Battery Optimization: Includes an integrated EQ function that balances cell performance, optimizing battery health and extending the system’s overall lifecycle.
Remote Intelligence: Monitor your energy production and consumption in real-time via the optional WiFi module and smart app connectivity.
Premium LiFePO4 Safety: Equipped with high-safety Lithium Iron Phosphate (LiFePO4) batteries, ensuring a reliable 10-year service life and stable energy discharge.
Advanced MPPT Technology: Built-in dual MPPT controllers maximize solar harvesting from your PV panels, ensuring high conversion efficiency even in low-light conditions.
Pure Sine Wave Performance: Delivers clean, stable pure sine wave output, protecting your sensitive electronics and home appliances from power surges.
Smart Battery Optimization: Includes an integrated EQ function that balances cell performance, optimizing battery health and extending the system’s overall lifecycle.
Remote Intelligence: Monitor your energy production and consumption in real-time via the optional WiFi module and smart app connectivity.
MS Series Portable Power Station delivers reliable, clean energy for demanding applications. It features high-efficiency MPPT technology for rapid solar charging, pure sine wave AC output (<3% THD) for sensitive electronics, and a long-life LiFePO4 battery system. Engineered with comprehensive circuit protection and intelligent cooling, it provides a professional-grade power solution for outdoor and emergency use.
